CITRONIC PPX300 2U POWER AMPLIFIER 2X 150W

Enquire Now
SKU 172.203 Categories , , , , Brand:

Description

19″ rackmount 2U power amplifiers with fan cooling and output protection. Balanced inputs via 6.3mm jack or XLR sockets, speaker outputs on 2 SPK connectors or 4mm binding posts. Switchable ground lift, bridge mode and clip limiter.

Product Specification

  • Power supply: 240Vac, 50Hz (IEC)
  • Controls: Level channel 1, level channel 2, ground, mode, clip limiter
  • Input impedance: 20k ohms
  • Frequency response: 5Hz – 50kHz
  • Total harmonic distortion: 0.05%
  • Slew rate: 40V/us
  • Damping factor: >400
  • Protection: Short-circuit, overload, D.C. and thermal protectPower rms @ 4 Ohms 150W + 150W
  • Power rms @ 8 Ohms: 100W + 100W
  • Power rms bridge @ 8 Ohms: 300W
  • Dimensions: 88 x 483 x 266mm (2U)
  • Weight: 8.2kg
