CITRONIC D41000 1U POWER AMPLIFIER 4X 1000W

SKU 172.149CT Categories , , , , Brand:

Description

Quad digital power amplifier in a lightweight 1U rack-mountable format. An energy-efficient switch-mode power section and class-D amplifiication circuit delivers accurate power-on-demand to four independent speaker outputs. Proprietary cool guide technology provides stable temperature management for dependable operation. Each pair of output channels can be separately parallel switched or bridged as a full or part stereo amplifier configuration. For channel A, there is a switchable 120Hz low-pass filter for use with subwoofers and a channels C and D have a switchable stereo pair of 120Hz high pass filters to effectively focus power in full-range cabs operating as mid-tops in conjunction with sub-woofers. For permanent or mobile installations, the D-series offers an invaluable and flexible problem solver for audio designers and sound engineers.

Features

  • Switchable bridge or parallel mono modes
  • Switchable high and low pass filters
  • Configurable as a quad, stereo or 2.1 system
  • Fully balanced audio signal path
  • Full audio and power protection with peak limiter

Product Documents

Product Specification

  • Weight: 6.400 kg
  • Dimensions: 482 x 320 x 44 mm (without feet)
  • Bridge Power @ 8 Ohms: 2 x 1800 W (both pairs of channels bridged)
  • Output – RMS @ 8 Ohms: 4 x 600 W
  • Output – RMS @ 4 Ohms: 4 x 1000 W
  • Power Supply (Powercon): 100–240 Vac, 50/60 Hz
  • Power Supply (IEC): 220–240 Vac, 50/60 Hz
  • Modes: 2 x Stereo, Parallel (Mono), Bridge (Mono)
  • Input Sensitivity: 0 dB = 0.775 Vrms
  • Crossover: Input A 120 Hz LPF and C+D 120 Hz HPF (all switchable)
  • Inputs: 4 x XLR female
  • Sound Output: 4 x SPK connectors
