CITRONIC – CSM-4 MUSIC MIXER WITH BT/USB/MP3

SKU: 170.871CT

Compact format audio mixer with 2, 4 or 6 mono input channels and a stereo line input. Each mono channel has a combo XLR/jack input with individually switchable mic/instrument impedance and +48V phantom power for the XLR. Input channels have High/Low EQ and Pan controls and mono channels also have Effects level to vary the amount of internal digital delay effect added for vocals or instruments. An internal player/recorder with backlit display can accept a USB memory stick containing compressed audio files in various formats or alternatively connect to a smart phone via BT wireless link. Output is delivered on a pair of balanced XLR connectors and offers very low noise operation for high quality studio or live performances.

Login to see prices Where To Buy

DESCRIPTION:

Product Description

Compact format audio mixer with 2, 4 or 6 mono input channels and a stereo line input. Each mono channel has a combo XLR/jack input with individually switchable mic/instrument impedance and +48V phantom power for the XLR. Input channels have High/Low EQ and Pan controls and mono channels also have Effects level to vary the amount of internal digital delay effect added for vocals or instruments. An internal player/recorder with backlit display can accept a USB memory stick containing compressed audio files in various formats or alternatively connect to a smart phone via BT wireless link. Output is delivered on a pair of balanced XLR connectors and offers very low noise operation for high quality studio or live performances.

SPECIFICATIONS:

  • Inputs: 2 x combo XLR/jack + stereo jack
  • Dimensions: 166 x 165 x 66mm
  • Power supply: 5Vdc 1A (adaptor included)
  • Power consumption: max.5W
  • Gain: -14 to +40dB
  • EQ: low: ±15dB @ 80Hz
  • EQ: high: ±15dB @ 12kHz
  • Phantom power: +48V individually switchable (XLR inputs only)
  • Input impedance : mic2k Ohms
  • Input impedance : instrument1M Ohms
  • Input impedance : line20k Ohms
  • Audio source: Internal USB player/recorder & BT receiver
  • Audio format: USB playback mp3, wma, ape, flac / record mp3 (48kHz 128kB/s)
  • Bluetooth version: 2.1 + EDR
  • Frequency response: 20Hz - 20kHz (±0.5B)
  • THD +N<0.03% : @ 1kHz
  • Dynamic range: 102dB
  • Crosstalk : stereo: 92dB
  • OutputLeft + Right balanced: XLR
  • Output impedance: 120 Ohms
  • Max. output level: 3Vrms
  • Weight: 0.89kg

FEATURES:

  • Integral USB multi-format audio player
  • BT wireless connectivity
  • Digital delay effect for vocals or instruments
  • Individually switchable +48V phantom power
  • Built in record function
  • Supplied with DC power adaptor

Product Documentation

170.871CT Product Manual
