DJPOWER DFZ-2100 HAZE MACHINE 1200W

Product Description

DFZ-2100 is a top of the range water-based haze machine designed for the professional market. It has strengthened its performance than its predecessor, comes built-in flight case and can be stacked one on another. DFZ-2100 haze machine features a unique heating system which enables to produce continuous even haze, free from clogging, reduce maintenance and extend product life. Operating at low noise levels makes it an ideal choice for noise-sensitive environments, including theaters, stages, studios and high-end bars.

SPECIFICATIONS:

• AC POWER Input Voltage & Rate: 220-240 V, 50/60 Hz
• Current Limiter Type: Breaker
• Current Limiter Specifications: 8 A, 250 V
• Total Power Consumption: 1,200 W
• Operating Current: 5.2 A
• Power Input Connector: Hard-wired HEATING Heat Up Time: Appr. 50 s
• Heater Type: Fast Coil Heater
• CAPACITY Fluid Tank Capacity: 5 L
• OUTPUT Adjustable Volume: √
• Volume Adjustment Level/Range: 1-100%
• Max Output Volume: Appr. 12,000 cuft/min
• Fluid Consumption @ full volume: Appr. 83 min/L
• Maximum Continuous Duration @ full volume: Unlimited
• Continuous Output: √
• Max Continuous Output Level: 100%
• Fully-loaded Cumulative Output Duration @ full volume: Appr. 416 min
• Consumable Type for Standard Output Test: PRO-C/PRO-J
• FEATURES Physical Thermostat: ×
• Electronic Thermo-Control: √
• Adjustable Output: √
• Adjustable Fan Speed: √
• No-Fluid Protection: √
• CONTROL On-device Manual Control: LCD control board
• Wireless Control: ×
• Wired Control: ×
• Control Protocol: DMX-512
• DMX Channel Range: 2
• Data Connectors: 3- and 5-pin XLR
• ACCESSORY Flight Case: √
• Power Cord: √
• Wireless Controller Model: ×
• Wired Controller Model: ×
• CONSUMABLE Consumable: PRO-C or PRO-J Haze Fluid
• WEIGHT & DIMENSIONS Net Weight: 17.8 kg
• Gross Weight: 19.8 kg
• Machine Dimensions: 530.8 × 409.8 × 276.4 mm
• Packing Dimensions: 590 × 475 × 335 mm

FEATURES:

• Continuous output, even and light haze
• 12,000cfm output, 0-100% precisely adjustable
• Nozzle free from fluid squirting
• Independent variable haze and fan control
• Powerful fan with low noise
• Low fluid consumption
• New heating system only 50 seconds heat-up time
• Advanced No-Fluid protection
• Patented long-life heating system
• Angle-adjustable haze outlet
• Anti-slip fluid tank
• Anti-leaking fluid system with quick-connect fittings
• Built-in LCD control, 3-pin and 5-pin DMX control
• Water-based fluid, no burnt odor, no harm to the optic
• Please use DJPOWER professional haze fluid PRO-C or PRO-J
