Power Dynamics – PRM120 100V MIXER-AMPLIFIER

SKU: 952.152PDM

The PRM series is a series rack-mountable amplifiers that can either be used as 100V amplifier or as a standard low-impedance amplifier. These amplifiers are equipped with BT receiver and USB/SD ports for MP3 playback including a bright LCD display with ID3 Tag. All PRM amplifiers are also provided with a switchable XLR input with 24V Phantom Power, especially for paging and condenser microphones. Especially designed for applications such as paging, announcements, intercommunications, background music, broadcasting in industrial plants etc.

Login to see prices Where To Buy

DESCRIPTION:

Product Description

The PRM series is a series rack-mountable amplifiers that can either be used as 100V amplifier or as a standard low-impedance amplifier. These amplifiers are equipped with BT receiver and USB/SD ports for MP3 playback including a bright LCD display with ID3 Tag. All PRM amplifiers are also provided with a switchable XLR input with 24V Phantom Power, especially for paging and condenser microphones. Especially designed for applications such as paging, announcements, intercommunications, background music, broadcasting in industrial plants etc.

SPECIFICATIONS:

  • Playback options: BT Streaming, SD-Card, USB
  • Output power:RMS: 120W
  • Impedance: 100V, 8ohm
  • Frequency Response: 50Hz - 18.000Hz
  • Signal-to-noise ratio: >75dB
  • Signal-to-noise ratio:Line: >85dB
  • Signal-to-noise ratio:Mic: >72dB
  • Power Supply: 100-240VAC 50/60Hz
  • Input level:Line: 150-470mV, 10kOhm
  • Input level:Mic: 5-8mV, 600Ohm
  • THD: <0,5%
  • Dimensions (L x W x H): 432 x 88 x 345mm
  • Weight : 9.1kg
  • Accessories: Power Cable

FEATURES:

  • 120W 100V amplifier
  • MP3 Player with USB/SD slots
  • Using BT wireless technology for audio streaming
  • LCD control panel with ID3 tag
  • 2x Mic/line inputs 6.3mm Jack, 2x RCA line inputs and 1x RCA line output
  • 2x XLR microphone inputs with switchable phantom power (24V) and VOX priority
  • 100V or 8 Ohm speaker output
  • Bass and treble controls
  • 19" Rack mountable (2U)
  • Emergency operation by 24V battery (not supplied)
  • Protections: Overheat, short circuit and power on delay
  • Emergency mute input
  • Including remote control

Product Documentation

952.152PDM Product Manual
