LS26 LINE SPLITTER 1:12 / 2:6

Product Description

2 input, 5 zone mixer with individual volumes for both inputs and a mono switch for each zone. All inputs and outputs are stereo via balanced XLR connectors. Acts as the central mix and control in an installation serving up to 5 separate stereo speaker zones.

SPECIFICATIONS:

• Power supply: 115/230Vac, 50/60Hz (IEC)
• Inputs: A & B, (6.3mm jack)
• Outputs: 1 - 6 & 7 - 12 (6.3mm jack)
• Input impedance: 20k Ohms
• Output impedance: 220 Ohms
• Frequency response: 20Hz - 20kHz, +0/-1dB
• Signal to noise ratio: >95dB
• THD: <0.008%
• Dimensions: 483 x 44 x 170mm
• Weight: 2.0kg

FEATURES:

• Up to 12 outputs from 1 or 2 inputs
• Individual volume control for each output
• Input peak LEDs
