FBT – ARCHON108W 8″ PASSIVE SPEAKER 350W RMS WHITE

SKU: 445.550FB

The Archon 108 is a 8″ and 1″ domed full-range passive speaker designed to provide ample bandwidth and high SPL for an accurate sound reproduction in the installed sound market perfect for modern indoor spaces.

Login to see prices Where To Buy
Categories: , , Brand:

Attributes:

  • Speaker Size: 8 Inch

DESCRIPTION:

Product Description

The Archon 108 is a 8″ and 1″ domed full-range passive speaker designed to provide ample bandwidth and high SPL for an accurate sound reproduction in the installed sound market perfect for modern indoor spaces.

SPECIFICATIONS:

  • Configuration: 2 Way
  • Frequency response: 60Hz - 22kHz
  • Low frequency woofer: 8" with 1.5" VC
  • High frequency driver: 1.5" Dome Tweeter
  • Maximum SPL cont/peak: 118/121dB SPL
  • Dispersion: 90 x 90 (H x V)
  • Crossover frequency: 2kHz
  • Input connector: 4x Euroblock
  • Net Dimension (WxHxD): 248 x 411 x 248mm
  • Net Weight: 6.5kg
  • Transport Dimension (WxHxD): 330 x 491 x 330 mm
  • Transport Weight: 8.5kg
  • Recommended Amplifier: 300w RMS

FEATURES:

  • 1 x 8” (1.5” VC) custom made LF woofer with rubber surround
  • 1 x 1.5” HF high-end dome tweeter
  • 8 x M5 threaded rigging points
  • 2-way, passive sound reinforcement systems
  • 12mm (0.47”) baltic birch plywood cabinets
  • Custom designed LF woofers, made in Italy
  • Custom designed HF dome tweeter, Made in Italy
  • Crossover networks equipped with 4 x Euroblock speaker terminals; factory preset for optimal line transformer installation
  • Multiple M5 threaded rigging points
  • Acoustically transparent steel grille and antidust protection cloth
  • New FBT rotatable logo badge following vertical or horizontal installation
  • Optional mounting hardware
  • Optional line transformer 100W
