BEAMZ – LCB183 LED BAR 18X 3W RGB

SKU: 150.705B

The LCB183 is a LED bar equipped with 18 x 3W pieces RGB LEDs. The LEDs are divided into 3 individually controllable sections of 6 LEDs each. While using the fixture in stand-alone mode there are pre-programmed shows that you can run automatically or sound activated, pick from the pre-set colour macros or create your own mixture of colours in RGB mode. The extra power output enables you to simply link the power of multiple units together into a single socket.

Login to see prices Compare Where To Buy

DESCRIPTION:

Product Description

The LCB183 is a LED bar equipped with 18 x 3W pieces RGB LEDs. The LEDs are divided into 3 individually controllable sections of 6 LEDs each. While using the fixture in stand-alone mode there are pre-programmed shows that you can run automatically or sound activated, pick from the pre-set colour macros or create your own mixture of colours in RGB mode. The extra power output enables you to simply link the power of multiple units together into a single socket.

SPECIFICATIONS:

  • Light source : 3-in-1 LED
  • LED colours : Red, Green, Blue
  • LED power : 3
  • Quantity of LEDs : 18
  • Beam angle : 35°
  • Flash rate per second : 1 - 14Hz
  • DMX channels : 3, 7, 12
  • DMX connector : 3-pin XLR
  • Modes : Automatic programs, DMX, Manual
  • IP rating : IP20
  • Cooling : Convection
  • Display : LED
  • Power plug : IEC
  • Power consumption : 0.41 - 0.21A
  • Power supply : 100-240VAC 50/60Hz
  • Dimensions (L x W x H): 1090 x 65 x 90mm
  • Weight : 1.9kg
  • Accessories : Mounting bracket, Power cable

FEATURES:

  • 18x 3W 3-in-1 LEDs
  • 3 Separate controllable sections
  • 2 Pre-programmed shows
  • 17 Auto mode programs
  • Sound activated
  • 3, 7 or 12 DMX channels
  • DMX and Stand-alone mode
  • DMX in/output via 3-pin XLR
  • Control panel with LED display

Product Documentation

150.705B Product manual
