ADASTRA Z5M ZONE MIXER

SKU: 953.019AD

2 input, 5 zone mixer with individual volumes for both inputs and a mono switch for each zone. All inputs and outputs are stereo via balanced XLR connectors. Acts as the central mix and control in an installation serving up to 5 separate stereo speaker zones.

Login to see prices Where To Buy

DESCRIPTION:

Product Description

2 input, 5 zone mixer with individual volumes for both inputs and a mono switch for each zone. All inputs and outputs are stereo via balanced XLR connectors. Acts as the central mix and control in an installation serving up to 5 separate stereo speaker zones.

SPECIFICATIONS:

  • Power supply115/230Vac 50/60Hz (IEC)
  • InputsLine 1 L+R, Line 2 L+R, balanced XLRF
  • OutputsZone 1 to 5 L+R, balanced XLRM
  • Input impedance40k Ohms
  • Output impedance220 Ohms
  • Frequency response20Hz - 25kHz, +0/-1dB
  • Signal to noise ratio>100dB
  • THD<0.005%
  • Dimensions483 x 175 x 44mm
  • Weight2.2kg

FEATURES:

  • 2 inputs to 5 zones
  • Mono selectable for each zone
  • Fully balanced XLR connections

Product Documentation

953.019AD Product manual
